Spartan-3 Starter Kit Board User Guide www.xilinx.com 5
UG130 (v1.1) May 13, 2005 1-800-255-7778
R
Preface
About This Guide
This user guide describes the components and operation of the Spartan™-3 Starter Kit
Board.
Guide Contents
This manual contains the following chapters:
•
Chapter 1, “Introduction”
•
Chapter 2, “Fast, Asynchronous SRAM”
• Chapter 3, “Four-Digit, Seven-Segment LED Display”
•
Chapter 4, “Switches and LEDs”
• Chapter 5, “VGA Port”
• Chapter 6, “PS/2 Mouse/Keyboard Port”
• Chapter 7, “RS-232 Port”
• Chapter 8, “Clock Sources”
• Chapter 9, “FPGA Configuration Modes and Functions”
• Chapter 10, “Platform Flash Configuration Storage”
• Chapter 11, “JTAG Programming/Debugging Ports”
• Chapter 12, “Power Distribution”
• Chapter 13, “Expansion Connectors and Boards”
• Appendix A, “Board Schematics”
•
Appendix B, “Reference Material for Major Components”
