RocketLinx ES9528 and ES9528-XT User Guide: 2000508 Rev. G Feature Overview - 39
Configuration Using the Web User Interface
PVLAN Port
Configuration
PVLAN Port
Configuration
on
Page 91
Port Configuration
• PVLAN Port Type - Normal, Host, or Promiscuous
• VLAN ID
PVLAN Association
• Secondary VLAN
• Primary VLAN
QoS Setting
QoS Setting on
Page 93
QoS Priority Mode
• Port-Based
• CoS
• DSCP
Queue scheduling
• Use Weighted Round Robin Scheme
• Use A Strict Priority Scheme
•
Rate Control
Rate Control on
Page 66
• Ingress Rate (1 Mbps to 100Mbps)
• Egress Rate (1 Mbps to 100Mbps)
Redundant Ring
Redundant Ring
on Page 81
• Ring ID and Name
• Ring Configuration
- ID
- Name
- Version (Super Ring and Rapid Super Ring)
- Device Priority
- Ring Port
- Path Cost
- Ring Port2
- Path Cost
- Rapid Dual Homing
- Ring Status
Redundant Ring
Information
Redundant Ring
Information
on
Page 82
• 32 Ring ID Maximum (0-31)
• Supports Up To 12 x 100M Rings Plus 2 Gigabit Rings
Aggregation Capability
• Version
• Role
• Status
• RM MAC
• Blocking Port
• Role Transition Count
• Ring State Transition Count
Type Category Details
