S e n d d o c u m e n t a t i o n c o m m e n t s t o n e x u s 5 k d o c s @ c i s c o . c o m
B-4
Cisco Nexus 5000 Series Hardware Installation Guide
OL-15902-01
Appendix B Technical Specifications
Power Specifications
Table B-9 lists the specifications for the Cisco Nexus 5020 1200 W power supply.
Specifications for the Cisco Nexus 5010 Power Supply
The power supplies connect to the system through panel mount connectors and connectors attach to the
baseboard through cables. There are total of three connectors on the baseboard: two for power delivery,
and one for power supply control signals.
Table B-10 lists the specifications for the Cisco Nexus 5010
power supply.
Input Voltage 100–120 V/200–240 V
Input Current 9.2 A/4.5 A
Frequency 50–60 Hz
RoHS Compliance Yes
Hot Swappable Yes
Heat Dissipation 2500 BTU/hr
Redundancy 1:1 (1200 W or 750 W)
Dimensions (H x W x D) 1.57 in. (0.039 m) x 4.00 in. (0.101 m) x 13.00 in.
(0.330 m)
Table B-8 Specifications for the Cisco Nexus 5020 750 W Power Supply (continued)
Description Specification
Table B-9 Specifications for the Cisco Nexus 5020 1200 W Power Supply
Description Specification
Typical Operating Power 480 W (Typical)
Max Power (system) 750 W
Input Voltage 100–120 V/200–240 V
Input Current 9.2 A/7.5 A
Frequency 50–60 Hz
RoHS Compliance Yes
Hot Swappable Yes
Heat Dissipation 2561 BTU/hr
Redundancy 1:1 (1200 W or 750 W)
Dimensions (H x W x D) 1.57 in. (0.039 m) x 4.00 in. (0.101 m) x 13.00 in.
(0.330 m)
Table B-10 Specifications for the Cisco Nexus 5010 Power Supply
Description Specification
Rated power 550 W
Input voltage 90–264 VAC
Frequency 47–63 Hz
