Chapter 1 Cisco Nexus 5500 Platform Overview
Cisco Nexus 5548P Switch
Connectivity Options—Transceivers and Cables
The Cisco Nexus 5500 Platform supports a wide variety of 1- and 10-Gigabit Ethernet connectivity
options using Cisco 10GBASE SFP+ modules. In addition, the Cisco Nexus 5548P supports 1-Gigabit
Ethernet connectivity options using 1GBASE SFP modules, 8-, 4-, and 2-Gbps Fibre Channel SFP+ and
4-, 2-, and 1-Gbps Fibre Channel SFP interfaces are supported with expansion module options.
This section includes the following topics:
• Transceivers, page 1-12
• Cables, page 1-14
Transceivers
The high bandwidth of 10-Gigabit Ethernet poses challenges to transmissions that are met by the
transceiver and cabling options supported by the Cisco Nexus 5500 Platform. Table
Table 1-4 lists the
supported transceiver options.
Table 1-4 Supported Transceivers
PSU Status
Indicators Power supply
(front) PSU Health
(multi color) Green OFF No AC power to power supply
Solid On Power supply on and OK
Amber Solid On Power supply failures, overvoltage,
overcurrent, overtemperature
1 Hz
blinking AC present, 3.3 VSB on,
PSU is off
OFF Operating normally
Chassis Locator Front of chassis Identify selected
chassis
Blue Solid on Chassis is selected
off Chassis is not selected
Table 1-3 LEDs for the Cisco Nexus 5548 Switch (continued)
LED Location Function Color Status Description
Cisco SFP Description
FET-10G 10G SFP+ module for Cisco Nexus 2000 Series to Cisco Nexus 5000
Series connectivity
Cisco SFP-10G-SR 10GBASE-SR SFP+ module (multimode fiber [MMF])
Cisco SFP-10G-LR 10GBASE-LR SFP+ module (single-mode fiber [SMF])
Cisco SFP-H10GB-CU1M 10GBASE-CU SFP+ cable 1 m (Twinax cable)
Cisco SFP-H10GB-CU3M 10GBASE-CU SFP+ cable 3 m (Twinax cable)
Cisco SFP-H10GB-CU5M 10GBASE-CU SFP+ cable 5 m (Twinax cable)
Cisco GLC-T 1000BASE-T SFP
Cisco GLC-SX-MM GE SFP, LC connector SX transceiver (MMF)
Cisco GLC-LH-SM GE SFP, LC connector LX/LH transceiver (SMF)
Cisco SFP-GE-T 1000BASE-T SFP, extended temperature range
