2-22
Cisco Nexus 5000 Series Hardware Installation Guide
OL-15902-01
Chapter 2 Cisco Nexus 5000 Series Overview
Cisco Nexus 5010 Switch
Table 2-7 lists the LED descriptions for all Ethernet LEDs.
Expansion Modules
Expansion modules allow Cisco Nexus 5000 switches to be configured as cost-effective 10-Gigabit
Ethernet switches and as I/O consolidation platforms with native Fibre Channel connectivity. The Cisco
Nexus 5010 switch has one slot for an optional uplink Gatos Expansion Module (GEM). The following
modules can be inserted in this slot: N5K-M1404, N5K-M1600, N5K-M1008 and N5K-M1060.
• N5K-M1404 provides 4 10G SFP+, and 4 Fiber Channel 1/2/4G SFP based uplink connections. The
10-Gigabit Ethernet ports are encryption capable.
• M5K-M1600 provides 6 10G SFP+ based uplink connections.
• N5K-M1008 provides 8 1-, 2-, and 4- Gps Fiber Channel, SFP based uplink connection.
• N5K-M1060 provides 6 1-, 2-, 4-, and 8-Gbps line rate Fiber Channel, SFP+ based uplink
connections.
The chassis supports hot swapping of the expansion modules.
This section includes the fllowing topics:
• N5K-M1404 Gatos Expansion Module, page 2-22
• N5K-M1600 Gatos Expansion Module, page 2-23
• N5K-M1008 Gatos Expansion Module, page 2-24
• N5K-M1060 Gatos Expansion Module, page 2-25
N5K-M1404 Gatos Expansion Module
The N5K-M1404 GEM supports four SFP+ transceiver modules and four 1-, 2-, 4-Gbps Fibre Channel
transceivers. The N5K-M1404 Fibre Channel plus Ethernet expansion module is a field-replaceable unit
(FRU).
Figure 2-24 shows the Fibre Channel plus Ethernet expansion module.
Table 2-7 Ethernet LED Descriptions
LED Status Description
Left Off No link
Solid green Physical link
Right Off No activity
Blinking green Activity
