Chapter 2 Cisco Nexus 5000 Series Overview
Cisco Nexus 5020 Switch
LED Descriptions
Table 2-3 describes the LEDs for the Cisco Nexus 5020 switch.
Table 2-3 LEDs for the Cisco Nexus 5020 Switch
LED Location Function Color Status Description
Chassis Front and back
of chassis Chassis
power and
health Green Solid on All diagnostics pass. The
module is operational.
Off The module is not receiving
power.
Amber On The module is booting or
running diagnostics.
An overtemperature condition
has occurred. The temperature
threshold has been exceeded
by a small value during
environmental monitoring.
Blinking An overtemperature condition
has occurred. The temperature
threshold has been exceeded
by a large value during
environmental monitoring.
If the module fails during an
initial reset, the LED
continues to blink and the
module does not come online.
The module has a runtime
failure and is brought offline.
Fan module Fan modules
(front) Fan
module
health
indicator Green Solid on All diagnostics pass. The
module is operational.
Off The module is not receiving
power.
Amber Solid on The module is booting or
running diagnostics.
Amber Blinking If the module fails during an
initial reset, the LED
continues to blink and the
module does not come online.
The module has a runtime
failure and is brought offline.
