2-8
Cisco Nexus 5000 Series Hardware Installation Guide
OL-15902-01
Chapter 2 Cisco Nexus 5000 Series Overview
Cisco Nexus 5020 Switch
Figure 2-9 N5K-M1008 GEM
Figure 2-10 Front View of the N5K-M1008 GEM
N5K-M1060 Gatos Expansion Module
The N5K-M1060 xpansion module provides 6 EA 1/2/4/8G line rate Fiber Channel, SFP+ based uplink
connections.
Figure 2-11 and Figure 2-12 show the N5K-M1060 GEM.
189953
189954
2
1 2 3 4 5 6 7 8
1
1 Eight 1-, 2-, 4-Gbps Fibre Channel ports 2 LED
