Chapter 1 Cisco Nexus 5500 Platform Overview
Cisco Nexus 5548P Switch
Figure 1-6 shows a front view of the expansion module.
Figure 1-6 N55 M16P GEM
N55 M8P8FP Gatos Expansion Module
The N55 M8P8FP Gatos Expansion Module (GEM) provides 8 1- or 10-Gigabit Ethernet and FCoE ports
using the SFP+ interface and 8 ports of 8-, 4-, 2-, 1 Gbps native Fibre Channel connectivity using the
SFP interface.
Figure 1-7 shows the N55 M8P8FP expansion module.
