S e n d d o c u m e n t a t i o n c o m m e n t s t o n x 5 0 0 0 - d o c f e e d b a c k @ c i s c o . c o m
1-10
Cisco Nexus 5000 Series Hardware Installation Guide
OL-15902-01
Chapter 1 Cisco Nexus 5500 Platform Overview
Cisco Nexus 5548P Switch
Figure 1-11 Blank Power Supply Filler Panel
Table 1-2 lists the power supply properties of the Cisco Nexus 5548P.
Table 1-2 Power Supply Properties of the Cisco Nexus 5548P Switch
Fan Modules
The Cisco Nexus 5548 switch has slots for two fan modules. If you insert two fan modules with six fans
in each module, your switch will have a total of 12 fans.
Figure 1-12 shows the fan module.
236711
AC Power Supply Properties Cisco Nexus 5548P Switch
Typical operating power 390 W
Maximum power 600 W (without the Layer 3 daughter card)
Input voltage 100 to 240 VAC
Frequency 50 to 60 Hz
Efficiency 95 to 98% (50 to 100% load)
RoHS compliance Yes
Hot swappable Yes
Heat dissipation 1998 BTU/hr (600 W)
