S e n d c o m m e n t s t o n 5 k d o c s @ c i s c o . c o m
3-31
Cisco Nexus 5000 Series Hardware Installation Guide
OL-15902-01
Chapter 3 Installing the Cisco Nexus 5500 Platform or 5000 Series Switch
Repacking the Cisco Nexus 5548P switch or the Cisco Nexus 5000 Series switch for Return Shipment
Removing the Cisco Nexus 5548P switch or the Cisco Nexus 5000 Series
Switch
Caution The slider rail and front rack-mount brackets do not have a stop mechanism when sliding in and out. If
the front of the chassis is unfastened from the rack and the chassis slides forward on the slider rails, it
may slip off the end of the rails and fall out of the rack.
To remove the Cisco Nexus 5548P switch or the Cisco Nexus 5000 Series switch from a rack, follow
these steps:
Step 1 Ensure that the weight of the switch is fully supported and that the switch is being held by another
person.
Step 2 Disconnect the power cord and the console cables.
Step 3 Disconnect all cables that are connected to SFP+ transceivers.
Step 4 Remove the screws fastening the front rack-mount brackets to the mounting rails.
Step 5 Gently slide the switch towards you, off of the slider rails and out of the rack.
Repacking the Cisco Nexus 5548P switch or the Cisco Nexus
5000 Series switch for Return Shipment
If you need to return the switch, remove the switch from the rack by following the steps in Removing
the Cisco Nexus 5548P switch or the Cisco Nexus 5000 Series Switch, page 3-31 , and repack it for
shipment. If possible, use the original packing materials and container to repack the switch. Contact your
Cisco customer service representative to arrange for return shipment to Cisco.
