HV-G/HW-G Series
7. Basic Operation
Description
The status of "Inactive comparator (
f6
)" is that comparator function (
f6 0
,
f6 2
,
f6 4
,
f6 6
) is selected and this comparator is not used. The comparator can be selected to
be ON or OFF using the SET key alternately.
The following parameters are stored in the same memory. Therefore these functions
can not be used at the same time. If you use each function, select the function in the
function table, set the parameters (HI,OK and LO) and weigh.
Indicator and Output
HI OK LO
Upper/Lower Comparator Function (
f6 0
to
7
) Upper limit
Lower limit
Simple Batch Function (
f6 8
)
Final
value
Preliminary
value
Zero band
Full/ Dribble Batch Function (
f6 9
)
Final
value
Preliminary
value
Zero band
