3-6 DP-V1 Service
3-35 - PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (IG) -
Execu
ting Communi
cat
ion
3
134 Output mode DINT R/W 0
0: NO
1: NC
135 Reserved for system
136 Hold function setting DINT R/W 0
0: Sample hold
1: Peak hold
2: Bottom hold
3: Peak-to-Peak hold
4: Auto peak hold
5: Auto bottom hold
137
Auto peak hold or auto
bottom hold trigger level
DINT R/W +00.100 -99.999 to +99.999
138 Timing Input DINT R/W 0
0: Level
1: Edge
139 Delay Timer DINT R/W 0
0: Delay timer OFF
1: On-delay timer
2: Off-delay timer
3: One-shot timer
140 Timer value DINT R/W 0060 1 to 9999
141 Hysteresis *18 DINT R/W 00.010 0 to 99.999
142 Analog Output Scaling DINT R/W 0
0: Default
1: Free range
143 Analog output Upper limit DINT R/W +10.000 -99.999 to +99.999
144 Analog output Lower limit DINT R/W 00.000 -99.999 to +99.999
145 External input *21 DINT R/W 0
0: Default
1: User setting
146 External input 1 *21 DINT R/W 0
0: Zero shift input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Do not use
147 External input 2 *21 DINT R/W 0
0: Reset input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Do not use
148 External input 3 *21 DINT R/W 0
0: Timing input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Do not use
149 External input 4 *21 DINT R/W 4
0: Gain input
1: Bank A input
2: Bank B input
3: Laser emission stop input
4: Do not use
150 Reserved for system
151
Saving the standard
waveform
DINT R/W 0
0: OFF
1: ON
152
Saving zero shift value
function
DINT R/W 0
0: OFF
1: ON
153 Interference prevention *22 DINT R/W 0
0: OFF
1: ON
Index
(DEC)
Function name Description
Data
type
Attribute
Default
value
Value
