3-6 DP-V1 Service
3-28 - PROFIBUS DP Compatible Network Unit DL-PD1 User's Manual (IG) -
Execu
ting Communi
cat
ion
3
86 External input response 1
When the request reception
to the "External input request
1" is complete, the
corresponding bit is set.
*1
2byte
WORD
R
bit0 : Reserved for system
bit1 : Slot 1
:
bit15 : Slot 15
87 External input response 2
When the request reception
to the "External input request
2" is complete, the
corresponding bit is set.
*1
2byte
WORD
R
bit0 : Reserved for system
bit1 : Slot 1
:
bit15 : Slot 15
88 External input response 3
When the request reception
to the "External input request
3" is complete, the
corresponding bit is set.
*1
2byte
WORD
R
bit0 : Reserved for system
bit1 : Slot 1
:
bit15 : Slot 15
89 External input response 4
When the request reception
to the "External input request
4" is complete, the
corresponding bit is set.
*1
2byte
WORD
R
bit0 : Reserved for system
bit1 : Slot 1
:
bit15 : Slot 15
90 External input response 5
When the request reception
to the "External input request
5" is complete, the
corresponding bit is set.
*1
2byte
WORD
R
bit0 : Reserved for system
bit1 : Slot 1
:
bit15 : Slot 15
91 to 95 Reserved for system
96
1st Sensor Head 1
Identification
Stores the type of the ID
number 1 sensor head (light
transmitter).
4byte
DINT
R
1: Light transmitter of IG-028
2: Light transmitter of IG-010
3: Not recognized or
connected
: : : : : :
110
15th Sensor Head 1
Identification
Stores the type of the ID
number 15 sensor head (light
transmitter).
4byte
DINT
R
1: Light transmitter of IG-028
2: Light transmitter of IG-010
3: Not recognized or
connected
111 Reserved for system
112
1st Sensor Head 2
Identification
Stores the type of the ID
number 1 sensor head (light
receiver).
4byte
DINT
R
1: Light receiver of IG-028
2: Light receiver of IG-010
3: Not recognized or
connected
: : : : : :
126
15th Sensor Head 2
Identification
Stores the type of the ID
number 15 sensor head (light
receiver).
4byte
DINT
R
1: Light receiver of IG-028
2: Light receiver of IG-010
3: Not recognized or
connected
127 Reserved for system
128 Product code 1
Stores the product code of ID
number 01 sensor amplifier. 2byte
WORD
R
: : : : :
142 Product code 15
Stores the product code of ID
number 15 sensor amplifier. 2byte
WORD
R
143 Reserved for system
144 Revision 1
Stores the revision of ID
number 01 sensor amplifier. 2byte
WORD
R 0101H to FFFFH
: : : : : :
158 Revision 15
Stores the revision of ID
number 15 sensor amplifier. 2byte
WORD
R 0101H to FFFFH
159 Reserved for system
Index
(DEC)
Function name Description
Data
type
Attribute Value
