T2 ® 37
T2 ® TransaXle parTs lIsT
1 Housing, Main
2 Housing, Side
7 Seal, Lip (included in Center Section Kit 202)
8 HFHCS 1/4-20 x 1 .25
10 Sealant, Loctite 5900
11 Oil, 20W50
13 Plug
20 Center Section
22 Bolt, Hex Flange
23 Plate, Bypass
24 Check Plug Assembly w/Washer
25 Check Plug/w Assembly w/Washer, .027, Spring
26 Bottom, Filter
27 Cover, Filter
28 Ring, Magnet
29 Deflector
30 Seal, Lip (included in Center Section Kit 202)
31 Ring, Retaining (included in Center Section Kit 202)
32 Rod, Actuator
33 Ring, Retaining (included in Center Section Kit 202)
34 Arm, Bypass
35 Ring, Retaining (included in Center Section Kit 202)
40 Trunnion, Swashplate
41 TWHCS 5/16-18 x 1 .00
42 Arm, Control
43 Screw, Set 5/16-24 x 2 .50
44 Washer , Belleville
45 Washer, Plastic .32 x .80 x .21
46 Washer .34 x .88 x .06
47 Spacer .32 x .59 x .50
48 Spring, Helical Comp
49 Nut, Hex 5/16-24 nylon insert
61 Input Shaft
62 Bearing, Ball 15 x 35 x 11
63 Ring, Retaining (included in Center Section Kit 202)
64 Washer 1 .23 x 1 .56 x .04
65 Seal, Lip (included in Center Section Kit 202)
66 Ring, Retaining (included in Center Section Kit 202)
67 Spring, Helical
70 Block, Cylinder 8cc
74 Bearing, Thrust 27 x 47 x 14
75 Block, Cylinder 10cc
79 Bearing, Thrust Ball 30 x 52 x 13
80 Ring, Retaining .50 External Motor Shaft (part of 202)
81 Gear, 13T Pinion
82 Shaft, Motor
83 Washer .60 x 1 .00 x .03
90 Gear
91 Gear, Jack Shaft 11T
92 Jack Shaft (Pin)
93 Washer .50 x 1 .00 x .03
100 Ring, Retainer (included in Center Section Kit 202)
101 Gear, Bevel 12T Spline ID
102 Gear, Bevel 12T .50 ID
103 Axle .75 dia . RH
104 Axle .75 dia . LH
105 Bushing, Inboard
106 Bushing, Outboard
107 Gear 53T Bull
108 Pin, Differential
109 Ring, Retaining Internal Axle (part of 202)
110 Seal, Lip .75 x 1 .125 x .25 TC (part of 202)
120 Puck, Brake
121 Rotor, Brake
122 Plate, Puck
124 Yoke, Brake
125 Pin, Brake
126 Spacer
127 Screw 1/4-20 x 2 .0 w/Patch
128 Screw 1/4-20 x 1 .0 w/Patch
129 Spring
130 Arm, Brake
131 Washer
132 Nut, Castle 5/16-24 PL
133 Pin, Cotter 3/32 x .75
134 Spring, Brake arm
140 5/16 SAE, 5/32 Tube
141 Hose
142 O-Ring .103 x .299 ID (part of 202)
143 Tank, Expansion
144 Bolt, Self Tapping 10-32 x 1/2, patch
145 Tube
146 Cap, Barbed Vent
150 Fan
151 Pulley
152 Nut
153 Washer
153 Screw 1/4-20 x 0 .75
160 Arm, Control RTN
161 Arm, Control RTN
162 Bolt, Hex Flange Head
163 Bushing
164 Assembly, RTN Bi-Directional
165 Arm, Neutral Assembly
166 Bushing
167 Spring
200 Kit, Filter
201 Center Section w/Filter
202 Center Section Kit
205 Seal Kit
206 Kit, T2 ® ROS
207 Kit, T2 ® ROS
