T2 ® 23
Refer to Figure 15
disassembly
1 . Remove all external items previously dis-
cussed in their recommended order .
2 . Remove the screws (8), separate side hous-
ing (2) from main housing (1) .
Inspection
1 . Inspect the bearing and bushing areas in the
side cover for wear or damage . Replace if
necessary .
sIde HOusInG
figure 15, side Housing removal
assembly
1 . Reassemble all parts in the reverse order
of disassembly .
2 . Apply a bead of sealant around the perim-
eter of the main housing face. See “Sealant
Application Diagram” on page 34.
3 . Align the side housing (2) with the main
housing (1) . Use care not to smear the seal-
ant bead .
4 . Install the housing screws (8) . Refer to the
screw tightening pattern on page 35 .
5 . When tightening the fasteners, refer to the
table on page 15 for the required torque
values .
8
Side Housing (2)
Main Housing (1)
