DVR User Manual
36
4.6.3 Email
Step 1: Enter into MenuSetupNetworkEmail tab. Refer to Fig 4-31:
SMTP Server/Port: The name and port number of SMTP server. Check the SSL
checkbox if the server requires a secure connection (SSL); user can setup mail
servers (such as Gmail) as required.
Send address/password:
Sender‟s email address/password
Receive address: Receiver‟s email address. Here user can add at least three
mail addresses. Click TEST button to test the validity of the mailbox.
Attaching image: After selecting it, the system will attach images when sending
the emails.
Fig 4-31 Network Configuration-Email
4.6.4 Server
This function is mainly used for connecting ECMS. The setting steps are as follows:
Step 1: In the server tab, select “enable” as shown in the Fig 4-32.
Step 2: Check the IP address and port of the transfer media server in the
ECMS. The default server port for auto report is 2009. If it is modified,
please enter into the transfer media interface to check.
Step 3: Enable the auto report in the ECMS when adding a new device.
Then input the remaining information of the device in the ECMS. After that,
the system will auto allot a Device ID. Please check it in the ECMS.
Step 4: Input the above-mentioned server IP, server port and device ID in
the server interface
.Then click “Apply” button to save settings. Now, the
ECMS system will automatically connect this device. Fig 4-32 Network Configuration-Server
