DVR User Manual
5
Step 3: Install other three HDD according to above-mentioned method. Then cover the upper iron bar and screw it firmly. Put the
HDD under it and screw firmly as shown below:
Step 4: Install other three HDD under the upper iron bar as shown below:
Step 5: Cover the back cover of the device and screw firmly.
2.1.2 Install DVD Writer
Step 1: Unscrew and open the case and then unscrew the screws in the both sides to take out of the upper iron bar as shown
below:
Step 2: Unscrew the four screws in the back of the front panel as shown below and then take out of the brace with a triangular
mark.
