4-5 62-02575-07
Display Cfg File
Configure
Figure 4-7. Configure Menu
To view a particular configuration file, select Display Cfg File and press .Use the arrow keys to select the file and
press to view the file.
To configure a container, select Configure and press to view the list of available configuration files. Using the
arrow keys, select desired file and press to send the configuration to the Controller. The new configuration will
take effect on Controller reset (power ON).
c. Display
This menu selection will present the user with another menu of available functions as shown below.
Compressor hour
Sensor offsets
Trip start date
Container ID
DataCORDER Cnfg
Figure 4-8. Display Menu
The user can select the desired function with the up, down and keys.
1 Compressor Hour
This menu item displays the total number of compressor hours. Press
to view the number of compressor run
hours.
2 Sensor Offsets
This menu item displays the sensor offsets and the display structure is as follows:
DataCORDER Rev. No. Probe No. (1st line) Current Reading offset (deg.C) (2nd line)
Press
to view the offsets of all the sensors configured in the system.
3 Trip Start Date
This menu item displays the trip start date based on the trip marker. If no trip marker was set, the display will be blank.
Press in this menu to view the trip start date.
4 Container ID
Container ID allows the user to view the current container ID. In this menu, press
to view the Container ID.
5 Container Configuration
Container Configuration allows the user to view the current configuration of the DataCORDER. In this menu, press
to view the DataCORDER configuration. The display will show:
1. Log Interval 2. Voltage 2 (IN or OUT)
3. Standard or Generic 4. CA probe (IN or OUT)
5. Sup & Ret (IN or OUT) 6. Humidity (%)
7. USDA (IN or OUT) 8. Therm. Log
9. CARGO (IN or OUT) 10. Network (Ave or Snapshot)
11. Voltage 1 (IN or OUT)
