Table 1-3. Temperature Controller Events -- Continued
Event
When Event Occurs
Data Sent
Limits
Trip Start (TS)
Any time trip start is en-
tered
NA
NA
USDA Trip Comment
When entered with
interrogation device
Up to 80 bytes of custom-
er comment data
Last 1 per day
Pre-Trip Data
Any time a Pre-Trip test is
completed and Controller
is configured to send indi-
vidual test data
Pass/Fail for each sub-test,
and appropriate data points
for each test
Unlimited
Economy Mode Start
(ECON_S)
Any time economy mode
is initiated
NA
NA
Economy Mode End
(ECON_E)
Any time economy mode
is terminated.
NA
NA
ISO Trip Comment
Changed
Whenever entered
Data entered by user
Last 1 per hour, last 1 per
day
Bulb Mode Start
(BULB_S)
Any time bulb mode starts
Evaporator fan speed,
DTT opening temperature,
dehumidification set point
NA
Bulb Mode End
(BULB_E)
Any time bulb mode ends
NA
NA
Controller Configuration
Change
Whenever changed by user Configuration information Last 1 per hour, last 1 per
day
Operating Mode Change Whenever unit changes
mode
New operating mode
Last 2 per hour, last 24 per
day
Power Management
Start
(Reciprocating Only)
Whenever power manage-
ment starts
Power management mode
Last 4 per hour, last 24 per
day
Power Management End
(Reciprocating Only)
Whenever power manage-
ment ends
Method used to end power
management
Last 4 per hour, last 24 per
day
Airslide Position
Change
(Reciprocating Only)
Whenever Makeup Vent
Slide Position is changed
Source of change com-
mand
Last 1 per hour, last 6 per
day
Phase Switching
(Scroll Only)
Whenever Phase Sequence
is Checked
Phase switched to correct/
incorrect
Last 6 per hour, last 24 per
day
Table 1-4 DataCORDER Events
Event
When Event Occurs
Data Stored
Limits
Case 1: Whenever an
alarm changes state
Case 1: Alarms active
during this hour
Case 1: 1 per hour which
is a combination of all
events in that hour
DataCORDER Alarm Ac-
tivity (DAL)
Case 2: At the end of any
hour where an alarm ac-
tive during that hour is in-
active at the end of the
hour
Case 2: Currently active
alarms
Case 2: 1 per hour
Battery Backup Start
(OFFWB)
Loss of main power with
battery pack present
NA
NA
Battery Backup End
(ONWB)
Restoration of AC power
with battery pack present
NA
NA
Power Loss (OFF)
Loss of AC power with no
battery pack present
NA
NA
