3-23 62-02575-07
Generic Configuration
The Recorder Generic Configuration allows the user to view and modify the current recorder configuration. The
Recorder Generic Configuration screen shows all of the sensors installed to a unit and whether they are configured to
be recorded. It allows the user to modify the recording interval, recorder sensors, and controller sensors. The following
screen is displayed when this option is chosen.
The following is a summary of the options available in Recorder Generic Configuration.
Recording Interval -- Allows the user to change the recording interval time 15 / 30 / 60 / 120 minutes.
Standard Configuration -- Allows the user to select a standard recorder configuration.
Recorder Sensors -- Allows the user to directly activate the recording of a sensor directly connected to the
Recorder. For further information, refer to the Recorder Sensors description below.
Controller Sensors -- Allows the user to directly activate the recording of a sensor connected to the Controller. For
further information, refer to the Controller Sensors description below.
Recorder Sensors -- Displays the configured recorder sensors.
Controller Sensors -- Displays the configured controller sensors.
Send -- Sends the new recorder configuration to the recorder. Upon completion the DataViewprogram informs the
user that the configuration was successfully sent to the recorder.
Help -- Displays the help screen.
Cancel -- Cancels the generic configuration and returns the user to the Recorder Configuration Screen.
