CD PLAYER
(DIN 45 500)
■ Audio
DA converter
1 bit2DACMASH
■ Pickup
Wavelength 780 nm
Laser power No hazardous radiation is emitted
(with safety protection)
■ General
Dimensions (WxHxD) 270x89.5x258.5 mm
Weight 2.1 kg
CASSETTE DECK
Deck system Stereo cassette deck
Track system 4-track, 2-channel
Recording system AC bias
Erasing system AC erase
Tape speed 4.8 cm/sec. ( 1 % ips)
Bias frequency
Heads 80 kHz
DECK 1 (playback) Permalloy head
DECK 2 (record/playback) Permalloy head
(erasure) Double gap ferrite head
Motors DC servo motor
Wow and flutter 0.1%(WRMS)
Fast forward and rewind time Approx. 110 seconds
with C-60 cassette tape
Frequency response (When Dolby NR OFF, CCRT ON)
NORMAL 20 Hz-17 kHz
30 Hz-15 kHz (DIN)
CrO> 20 Hz-18 kHz
30 Hz-17 kHz (DIN)
METAL
S/N (CrOi type tape)
20 Hz-20 kHz
30 Hz-19 kHz (DIN)
Dolby NR off 56dB(A-WTD)
Dolby B NR on 66 dB(CCIR)
Dolby C NR on 74dB(CCIR)
■ General
Dimensions (WxHxD)
270x119x262 mm
Weight 3.3 kg
SPEAKER SYSTEM
[SB-CH950]
Type
Speaker(s)
Impedance
MAIN
SURROUND
Input power
MAIN
SURROUND
Output Bound preasure
Crosa over frequency
Frequency range
■ General
DImenaiona (WxHxD)
Weight
[SB-CH750]
туре
Speaker(a)
Impedance
MAIN
SURROUND
Input power
MAIN
SURROUND
Output aound preaaure level
Croaa over frequency
Frequency range
■ General
DImenaiona (WxHxD)
Weight
3 way/surround, 4 speakers, bass-reflex
Woofer 17 cm cone type
Midrange 2.5 cm dome type
Tweeter dome type
Surround 8 cm cone type
60
80
120 W (music), 60 W (DIN)
20 W (music), 10 W (DIN)
level 86 dB/W( 1 . 0 m)
1.5 kHz, 6 kHz
33 Hz-25 kHz (-16 dB)
238x416x288 mm
6.0 kg
3 way/surround, 4 speakers, bass-reflex
Woofer 17 cm cone type
Midrange 2.5 cm dome type
Tweeter dome type
Surround 7 cm cone type
60
80
120 W (music), 60 W (DIN)
10 W (music), 5 W (DIN)
86dB/W(1.0m)
1.8 kHz, 6 kHz
33 Hz-22 kHz (-16 dB)
240x416x293 mm
5.5 kg
Notes:
1. Specifications are subject to change without notice.
Weight and dimensions are approximate.
2. Total harmonic distortion is measured by the digital spectrum
analyzer.
