Setup Utility
Supervisor Setup
If a supervisor password has been set, the password input screen will appear. Input the
supervisor password.
Supervisor Setup
Parallel Port [Port378, IRQ / n
Mode [ Bidirectional ]-
DMA None-----------------
Infrared Port [ Port 2F8, IRQ i i]
ASK Mode [ Disabled ]
DMA [DMA 0 ]
Serial Port [ Port3F8, IRQ^ n
Sound Port [ Enabled ]
Sound Blaster compatible I/O [220h ]
WSS CODEC I/O [530h ]
IRQ [ IRQ 5 ]
DMA-A [DMA 7 ]
DMA-B {Sound Blaster) [DMA 1 ]
USB Port [ Disabled
]
Boot up Drive t FDD -> HDD ]
'Supervisor Password-----------------------------------------------
User Password protection by user [Disable ]■
PCI clock control* [ Enable ] ■
Q=page 38
(To display the items marked with an asterisk (*), move the cursor to the
bottom of the screen to cause it to scroll down.)
[Sound Port]
Select the sound chip operation setting. If [Disabled] is selected, all sound related
settings are disabled.
[Sound Port: Sound Blaster compatible I/O]
Set the I/O address for the Sound Blaster compatibility mode.
[Sound Port: WSS CODEC I/O]
Set the I/O address for WSS CODEC.
[Sound Port: IRQ]
Set the IRQ for the sound chip.
It is not possible to select the same IRQ as that selected for the parallel port.
[Sound Port: DMA-A] [Sound Port: DMA-B]
Set the DMA for the sound chip. Make sure that the settings for DMA-A and DMA-
B do not overlap, and that neither of them overlaps with the DMA setting for the
parallel port or the infrared port.
