Add-ons/Peripherals
Devices capable of being used by your computer are listed in the table below.
Device(s) Where to connect Reference
Port Replicator Expansion Bus Connector below
External Floppy Disk FDD Port Q=page 45
PC Cards (Modern, LAN, SCSI, etc.) PC Card Slots (3^pagc 46
Serial Devices (Mouse, Modem, etc.) Sérial Port Q^page 44
Extra Memory RAM Module Slot Q^page 48
External Display Ext. Display Port Cépage 50
Printer Parallel Port ( 3 >page 51
Keyboard, External Mouse [Type PS/2], etc. Ext. Keyboard/Mouse Port Q=page 44
Speaker/Headphone Headphone Jack Q=page 9
Microphone Microphone Jack G^page 9
n
Do not install or remove peripherals while your computer is in the suspend or
hibernation mode; abnormal operation may result.
Connecting/Disconnecting the Port Replicator
Connect the port replicator to the computer before connecting devices such as an ex­
ternal floppy disk drive or an external display.
1
Power off your computer
(G’page 18)
Do not shut down using the suspend or hibernation mode.
2
Disconnect the AC adapter
3 Close the display, then turn your computer over
4
If an Extended life Battery Pack (CF-vzsuoe) is connected
to your computer, remove it (cépage 32)
If you are using the included battery pack, it does not need to be removed.
