3D Disto, Instrument Setup 78
2. If needed, press in the setup screen to activate PC connection. The
Control Unit is now entirely controlled by the connected PC.
3. If connection is not working go to Menu and select Connect to PC.
4. After successful connection, a pop-up window with the Import folder appears at
your PC screen.
5. Copy the files from the PC to the Import folder on the Control Unit and close the
window.
6. Disconnect Control Unit by choosing Disconnect Hardware at your PC or by key
press in the pop-up of the Control Unit.
7. Open File Manager and press . Available DXF files are listed. Choose a file and
press .

Ensure Control Unit is not connected by USB cable to 3D Disto otherwise
connection to PC is not working.
