111 3D Disto, Software Applications
Comfort targeting
step-by-step 1. Start application in Menu » Applications » Tool Kit.
2. The running application stays open in the background.
3. Press on the Toolbar.
4. Viewfinder opens. Target reference point on the wall. Press .
5. Pop-up prompts to enter value for left or right distance to reference point. For
left turn set a negative value. Press OK to confirm the value.
6. Laser point flashes to indicate exact position. Pop-up appears to enter vertical
value (= distance above/below layout point). Default value = 0. Set a negative
value for down turn. Press OK to confirm the value.
7. 3D Disto turns and lays out the correct position.
8. Laser point flashes to indicate exact position.
9. Press to close Tool Kit.

Enter 0 to lay out points with only vertical offsets to the reference
point.

Refer to "8 Error Messages" for information about possible error
messages.
