3D Disto, Software Applications

164

2. Each point and line can be selected by fingertip or stylus.
3. The grid can be moved up, down, left, and right on the screen in small steps using

/

/

/

. The perpendicular distance from a selected grid point to a

reference line is displayed. Tap on this distance to enter a value.

4. Press

for further grid alignment tools.

5. Press

to reset the grid position.

6. Press

to align grid parallel to a selected line.

7. Press

to turn the grid by 90°.

8. Press

to place the grid exactly on a reference point.

9. Press

to

proceed.

Lines between design points can be drawn on the screen if necessary
before use of the Parallel tool.

Use the

key at any time to go back to Point Design.
