3D Disto, Software Applications 162
• Measure: follow the guided workflow to lock onto an existing grid. This option
skips the following step Adjustment.
• Import mode
1. Press to start Import mode.
2. The file manager displays all imported DXF and CSV files. Select a file. Press
if you want to check the content via viewer.
3. Press to continue.
4. Projection points are displayed and ready for adjustment.

The head line of the viewer displays the dimension of the file. Change
the setting for distance in the menu if the scale does not fit to the
working area!

To import points from a list, enter coordinates X, Y or Y; X in a text
editor and save the file with extension CSV. If the import does not work
properly check the Import/Export settings in the menu.
