157 3D Disto, Software Applications
Surface scan,
step-by-step 1. Press for surface scan.

4. The Viewfinder opens for measurements to define the scan area:
• horizontal & vertical scan: measure 2 edges (3 points). The area is completed
automatically
• slope scan: measure the borders of the scan area and press to continue.
2. Pop-up offers three scan options: horizontal,
slope and vertical. Select your preference
according to the surface you want to scan.

Use vertical or horizontal scan to measure on walls, floor and ceiling.

Slope scan is ideal to check the flatness of any surface, independent of
it’s inclination.
3. Select “precise” or “speedy” option. “Precise”
finds the exact position of each scan point.
“Speedy” prioritises short measuring time and
robustness. Measurement accuracy is equal.
