Parameter Function
CAM 1 to CAM
16 channel 1 to channel 16
Open all /close
all Click this button to open all video channels.
Once all video channels are open, it becomes close all button.
Local play Click local play button to select file to play in PC.
Refresh Click this button to refresh monitor channel name.
Please left click one monitor to view real-time video, the monitor window is shown as in Figure
8-5.
Figure 8-5 Real-time Monitor
Please refer to the following sheet for monitor window parameter information.
Parameter Function
Display device
information
 1: NVR IP address.
 2: Channel number.
 3: Bit stream.
 4: Bit stream decode type.
 S1: Overlay.
 S2: Off stream.
 S3:GD1
 H1: Overlay
 H2: off stream decoding from the display card.
Digital zoom Click this button and then left drag the mouse in the zone
to zoom in. Right click mouse system restores original
status.
Change show
mode Resize or switch to full screen mode.
Local record When you click local record button, the system begins
recording. The recorded file is saved to system folder: \
RecordDownload(default).
Snapshot You can snapshoot important video. All images are
memorized in system folder: \ picture download (default).
Audio Turn on or off audio.
Close video Close video in current window.
