DVR systems NVR38xx Series - Manual (Page 28)

28
3 HDD Installation
For the first time install, please be aware that whether the HDDs have been installed.
Strongly recommended to use the HDDs which we suggest you to use (high speed HDD that above 7200
rounds), we do not suggest you to use PC specified HDD.
3.1 1U Series
Pleas follow the steps listed below to install the HDD.
① Remove screws on the ②Fix the four screws on the ③Place the HDD in accordance
rear panel and the side panel. HDD (rotate three rounds) to the four holes.
④Turn the device upside down⑤ Fix the HDD on the bottom panel. ⑥ Insert the HDD wire and power
and then insert the screws to cable
the bayonet and fix them
.
⑦ Uncover the box cover. ⑧Fix the screws on the rear & side panel.
