DVR systems NVR38xx Series - Manual (Page 11)

11
Network
Monitor

Through network, sending audio/video data compressed by IPC or NVS
to client-ends, then the data will be decompressed and display. If
bandwidth is big enough, latency is less than 500ms

Support max 10 connections

Transmit audio/video data by HTTP, TCP, UDP, MULTICAST, RTP/RTCP
and etc.

Transmit some alarm data or alarm info by SMTP.

Support WEB access in WAN.
Window Split

Adopt the video compression and digital process to show several
windows in one monitor. Support 1/4/9/16-window display.
Record

Support schedule record function. Save the recorded files in the HDD,
client-end PC, or network storage server. You can search or playback the
saved files at the local-end or via the Web.
Backup

Support network backup, USB record backup function, the recorded files can
be saved in network storage server, peripheral USB device, burner and etc.
Network
Management

Supervise NVR configuration and control power via Ethernet.

Support management via WEB.
Peripheral
Equipment
Management

Support peripheral equipment management such as protocol setup and
port connection.

Support transparent data transmission through RS232/RS485.
Auxiliary

Support switch between NTSC and PAL.

Support real-time system resources information and running statistics
display.

Support log file.

Local GUI output. Shortcut menu operation via mouse.

IR control function. Shortcut menu operation via remote control.

Support IPC or NVS remote video preview and control.
1.3 Specifications
Parameter
Specification
1U Series 2U Series
System
Resources
Max. support 16-ch standard definition with the transmission rate of 2mbps for each
channel;
8-channel 720P, with the transmission rate of 4mbps for each channel;
4-channel 1080P, with the transmission rate of 8mbps for each channel;
Support 20 online users at the same time,
The image delay time of each channel is under 500ms.
