Parameter
Function
tour &pattern when there is an alarm.
8.3.2.2 PTZ
PTZ interface is shown as in Figure 8-37
Please note, before operation please make sure you have set speed dome address and the NVR
and speed dome connection is OK.
Figure 8-37 PTZ
Please refer to the following sheet for detailed information.
Parameter Function
Channel
You can select monitor channel from the dropdown list. .
Protocol
Select the corresponding dome protocol.(such as PELCOD)
Address
Set corresponding dome address. Default value is 1. Please note your
setup here shall comply with your dome address; otherwise you can
not control the speed dome.
Baud
Rate
Select the dome baud rate. Default setup is 115200.
Data Bit
Default setup is 8. Please set according to the speed dome dial switch
setup.
Stop bit
Default setup is 1. Please set according to the speed dome dial switch
setup.
Parity
Default setup is none. Please set according to the speed dome dial
switch setup.
8.3.2.3 Default & Backup
Default: Restore factory default setup. You can select corresponding items.
Backup: Export current configuration to local PC or import configuration from current PC.
Please refer to Figure 8-38.
