DVR systems NVR38xx Series User Manual
Page 105
105
Figure 8-36 Detect
Parameter
Function
Event type
Motion detect, video loss and video masking
Channel
select the channel to activate recording function
Sensitivity
System supports 6 levels. The sixth level has the highest sensitivity.
Enable button
Tick to enable
Region
There are PAL22X18/NTSC22X15 small zones.
Blue area is the detection zone. Right click to view in full screen, click OK
before exit to save the setup.
Period
Here you can set for business day and non-business day.
Anti-dither
Range: 0～600
Alarm output: s.
when alarm occurred, system enables peripheral alarm device
Record channel
Select the recording channel (can be selected more than once) , this channel
will be activated to record when alarm occurs.
Latch
When motion detection complete, system auto delays detecting for a specified
time. The value ranges from 10-300(Unit: second)
Send email
System can send out email to alert you when alarm occurs.
Tour
Here you can enable tour function when alarm occurs.
PTZ activation
Here you can set PTZ movement when alarm occurs. Such as go to preset,
