33
6 GUI Operation
Connect the device to the monitor, insert the mouse and connect the power cable. Push the on/off
button in the rear panel and then you can see the analog video output. You can use the mouse to
implement some simple GUI operation. Please refer to the following chapter for detail information.
All the operations listed below are based on our 16-ch series device.
6.1 Login
After device booted up, the system is in multiple-channel display mode. See Figure 6-1.
You can overlay the corresponding date, time and channel name on each screen. You can refer to
the following sheet for channel record or alarm status information.
Figure 6-1
Right click mouse, you can see the login interface. Please input user name and password. See
Figure 6-2.
System consists of four accounts:
 Username: admin. Password: admin.
 Username: 888888. Password: 888888.
 Username: 666666. Passwords: 666666.
 Username: default.
You can use USB mouse to input. Click to switch between numeral, English character
(small/capitalized) and denotation.
Note:
For security reason, please modify password after you first login.
Within 30 minutes, three times login failure will result in system alarm and five times login failure
will result in account lo
1 Recording status 3 Video loss
2 Motion detection 4 Camera lock
