2240 Fiber Optic Modem User Manual Chapter 7 Specifications
Indicators and Controls
94
Power Requirement
7.3 Indicators and Controls
7.4 Physical and Environmental
Standalone 115 VAC +10% @ 0.22 amps
115/230 VAC + 10% switchable
@0.11 amps 47 to 63 Hz
Rack mount PC card 18 VAC +10% @ 1.1 amps per board
50 to 64 Hz
Indicators (6) Tx/Rx data activity
Local/remote sync
Loopback active
Power on
Power alarms (2201 Rack only)
Controls (10) Local/remote loopback slide switch
Operating mode DIP switch
Data rate DIP switch
Hi/Low optic power DIP switch
Dimensions:
2240-S Standalone
PC Card
12.8" L x 8.5" W x 2.5" H
12.5" L x 7.8" W x 1.06" H
Unit Weights (shipping):
2240-S Standalone
PC Card
3.63 lbs
0.9 lbs
Operating Environment:
Temperature
Humidity
0 to 50° C
0 to 95% non-condensing
