Page 93: System electrical
Chapter 7 Specifications
System Electrical
93
7.1.1 Distance Guide
NOTE: These typical distances depend on the quality of the fiber cable plant.
7.2 System Electrical
Interface Connector
Interface
Connector Type
RS-232C/423/530
female DB-25
Programmable RS-530 (P53)
female DB-25
RS-422 (422)
female DC-37
CCITT V.35 (V.36)
female 34-pin Winchester
TTL/BNC
four female BNC coaxial
RS-422 Mil-Std 188-114C
four or five female Twinaxial connectors BJ-77 (3-lug)
Transparent T1/E1
Female DA-15, two female BNC connectors or terminal strip
Interfaces supported
RS-232D/RS-423
RS-449
CCITT V.35
TTL/BNC
Programmable RS-422 (P)
TwinAx 422
TwinAx MIL-STD-188-114C
DC-37 MIL-STD-188-114
Transparent T1/E1
CCITT V.35/RS-423 (MC2), RS-449/423 (MC1)
RS-530
1310 nm HP SMF
0
1310 nm HP laser SMF
1310 nm LP laser SMF
1310 nm LP laser MMF
850 nm LED MMF
10
20
30
Kilometers
40
50
60
70
80
90
100
