- 3 -

Betriebsarten
• Einkanaliger Betrieb

- ein Eingangskreis wirkt auf beide Kanäle
- keine Redundanz (Ausfallsicherheit) im

Eingangskreis

• Zweikanaliger Betrieb

- zwei redundante (d. h. identische) Ein-

gangskreise wirken auf Kanal 1 und
Kanal 2

- Überwachung der Kontakte im Eingangs-

kreis (Ausfallsicherheit gegen Kurz-
schluss)

• Manueller Start

- Ansteuerung des Startkreises mit

Starttaster oder Startkontakt

• Automatischer Start

- die Ausgangsrelais ziehen an, sobald die

Eingangskreise geschlossen sind

- für NOT-AUS-Stromkreise ist diese Be-

triebsart nicht zulässig, da die Anlage
nach Spannungsausfall und -wiederkehr
selbsttätig anläuft.

Montage

Das Gerät muss in einen Schaltschrank mit ei-
ner Schutzart von mind. IP54 eingebaut wer-
den. Zur Befestigung auf einer Normschiene
hat das Gerät ein Rastelement auf der Rück-
seite.
Sichern Sie das Gerät bei Montage auf einer
senkrechten Tragschiene (35 mm) durch ein
Halteelement wie z. B. Endhalter oder
Endwinkel.

Inbetriebnahme

Beachten Sie bei der Inbetriebnahme:
Vor die Ausgangskontakte eine Sicherung

(siehe techn. Daten) schalten, um das
Verschweißen der Kontakte zu verhindern.

• Keine kleinen Ströme mit Kontakten

schalten, über die zuvor große Ströme
geführt wurden.

• Hilfskontakt 41-42 nicht für Sicherheits-

stromkreise verwenden!

• Berechnung der max. Leitungslänge I

max

im

Eingangskreis:

R

lmax

R

l

/ km

I

max

=

R

lmax

= max. Gesamtleitungswiderstand (s.

technische Daten)
R

l

/km = Leitungswiderstand/km

• Leitungsmaterial aus Kupferdraht mit einer

Temperaturbeständigkeit von 60/75 °C
verwenden.

• Angaben im Kapitel "Technische Daten"

unbedingt einhalten.

Anschluss
• Verzögerungszeit für Sicherheitskontakt

57-58 mit Hilfe eines Schraubendrehers
festlegen.

• Versorgungsspannung an Klemmen A1 (+)

und A2 (-) anschließen.

• Eingangskreis: NOT-AUS-Taster oder

Sicherheitsendschalter anschließen:
- Einkanaliger Betrieb: Eingangskreis an

S11 und S12 anschließen; Brücke
zwischen S12-S22 einlegen.

- Zweikanaliger Betrieb: Eingangskreise an

S11, S12 und an S11, S22
anschließen.

Operating modes
• Single channel operation

- one input circuit operates both

channels

- no redundancy (fail-safe) in the input

circuit

• Two channel operation

- two redundant (i.e. identical) input

circuits operate channel 1 and channel 2

- monitoring of the contacts in the input

circuit (fail-safety in the event of short
circuit)

• Manual reset

- Control of a reset circuit with a reset

button or a reset contact

• Automatic reset

- the output contacts energise as soon

as the input circuit is closed

- this mode of operation is not

permissable for Emergency Stop
circuits as the installation is activated
independently following a loss/return of
supply voltage

Installation

The unit must be panel mounted (min.
IP54). There is a notch on the rear of the
unit for DIN-Rail attachment.
If the unit is installed on a vertical mounting
rail (35 mm), ensure it is secured using a
fixing bracket such as end bracket.

Operation

Please note for operation:
• To prevent a welding together of the

contacts, a fuse (see technical data)
must be connected before the output
contacts.

• Low currents should not be switched

across contacts across which high
currents have previously been switched.

• Auxilliary contact 41-42 are not to be

used for safety circuits.

• Calculate the max. Cable runs I

max

in the

input circuit:

R

lmax

R

l

/ km

I

max

=

R

lmax

= Max. Total cable resistance (see

technical details)
R

l

/km = Cable resistance/km

• Use copper wiring that will withstand

60/75 °C

• Important details in the section

„Technical Data“ should be noted and
adhered to.

Connection
• Adjust the desired delay time of contact

57-58, using a screwdriver

• Connect the operating voltage between

A1

i

(+) and A2 (-).

• Input circuit

Connect the E-Stop button or safety limit
switch:
- Single channel operation: Connect

input circuit to S11 and S12; bridge
S12-S22.

- Two channel operation: Connect input

circuit to S11, S12 and to S11, S22.

Mode de fonctionnement
• Commande par un canal

- Le circuit d'entrée agit sur les deux

canaux.

- Pas de redondance dans les canaux

d'entrée .

• Commande par deux canaux

- deux circuits d'entrée redondants (c.à.d

identiques) agissent sur les canaux 1 et 2.

- Surveillance des contacts dans les

circuits d'entrée (détection de la
défaillance d'un contact de l'AU)

• Réarmement manuel

- réarmement par bouton poussoir ou

contact externe .

• Réarmement automatique

- les relais de sortie montent dès que les

canaux d'entrée sont fermés.

- Attention ! En cas de réarmement

automatique, la montée du relais ne doit
pas remettre votre installation sous
tension.

Montage

Le relais doit être installé dans une armoire
équipée d'une protection IP54. Sa face
arrière permet un montage sur rail DIN.
Immobilisez l'appareil monté sur un rail DIN
vertical (35 mm) à l'aide d'un élément de
maintien comme par ex. un support ou une
équerre terminale.

Mise en oeuvre

Remarques préliminaires :
• Protection de contacts de sortie par des

fusibles (voir caractéristiques
techniques) pour éviter leur soudage.

• Ne pas commuter de petites intensités

avec des contacts qui ont précédemment
coupé de fortes intensités.

• Ne pas utiliser le contact de signalisation

41-42 pour les circuits de sécurité.

• Calcular les longueurs de câblage max I

max

dans le circuit d’entrée:

R

lmax

R

l

/ km

I

max

=

R

lmax

= résistivité de câblage totale max.

(voir les caractéristiques techniques)
R

l

/km = résistivité de câblage/km

• Utiliser uniquement des fils de cablâge en

cuivre 60/75 °C.

• Respecter les données indiquées dans le

chapitre "Caractéristiques techniques".

Branchement
• Régler la temporisation du contact 57-58 à

l'aide d'un tournevis

• Ramener la tension d'alimentation (A1/A2)
• Canaux d'entrée :

Câblage de l'interrupteur de position ou
d'Au :
- Commande par un canal : câbler le

circuit d'entrée aux bornes S11 et S12;
ponter les bornes S12-S22.

- Commande par deux canaux : câbler les

canaux d'entrée aux bornes S11, S12 et
aux bornes S11, S22.
