- 1 -

Safety Regulations

• The unit may only be installed and

operated by personnel who are familiar
with both these instructions and the
current regulations for safety at work and
accident prevention. Follow VDE and
local regulations especially as regards
preventative measures.

• Transport, storage and operating

conditions should all conform to EN 60068-
2-6.

• Any guarantee is void following opening of

the housing or unauthorised
modifications.

• The unit should be panel mounted,

otherwise dampness or dust could lead to
function impairment.

• Adequate protection must be provided on

all output contacts especially with
capacitive and inductive loads.

• Note for overvoltage category III:

If voltages higher than low voltage
(>50 VAC or >120 VDC) are present on
the unit, connected control elements and
sensors must have a rated insulation
voltage of at least 250 V.

Sicherheitsbestimmungen

• Das Gerät darf nur von Personen

installiert und in Betrieb genommen
werden, die mit dieser Betriebsanleitung
und den geltenden Vorschriften über
Arbeitssicherheit und Unfallverhütung
vertraut sind. Beachten Sie die VDE-
sowie die örtlichen Vorschriften, insbe-
sondere hinsichtlich Schutzmaßnahmen.

• Beim Transport, der Lagerung und im

Betrieb die Bedingungen nach EN 60068-
2-6 einhalten (s. technische Daten).

• Durch Öffnen des Gehäuses oder eigen-

mächtige Umbauten erlischt jegliche Ge-
währleistung.

• Montieren Sie das Gerät in einen Schalt-

schrank; Staub und Feuchtigkeit können
sonst zu Beeinträchtigungen der Funktio-
nen führen.

• Sorgen Sie an allen Ausgangskontakten

bei kapazitiven und induktiven Lasten für
eine ausreichende Schutzbeschaltung.

• Hinweis für Überspannungskategorie III:

Wenn am Gerät höhere Spannungen als
Kleinspannung (>50 V AC oder
>120 V DC) anliegen, müssen ange-
schlossene Bedienelemente und Senso-
ren eine Bemessungsisolationsspannung
von mind. 250 V aufweisen.

Conseils préliminaires

• La mise en oeuvre de l’appareil doit être

effectuée par une personne spécialisée
en installations électriques, en tenant
compte des prescriptions des différentes
normes applicables (NF, EN, VDE...)
notamment au niveau des risques
encourus en cas de défaillance de
l’équipement électrique.

• Respecter les exigences de la norme

EN 60068-2-6 lors du transport, du
stockage et de l'utilisation de l'appareil.

• L’ouverture de l’appareil ou sa modifi-

cation annule automatiquement la
garantie.

• L’appareil doit être monté dans une ar-

moire; l’humidité et la poussière pouvant
entraîner des aléas de fonctionnement.

• Vérifiez que le pouvoir de coupure des

contacts de sortie est suffisant en cas de
circuits capacitifs ou inductifs.

• Remarque relative à la catégorie de

surtensions III :
Si l’appareil est alimenté avec des tensions
supérieures à la basse tension (>50 V AC
ou >120 V DC), les éléments de
commande et les capteurs raccordés
doivent supporter une tension d’isolement
assignée d’au moins 250 V.

Bestimmungsgemäße Verwendung

Das Sicherheitsschaltgerät dient dem
sicherheitsgerichteten Unterbrechen eines
Sicherheitsstromkreises.
Das Sicherheitsschaltgerät erfüllt Forderun-
gen der EN 60947-5-1, EN 60204-1 und
VDE 0113-1 und darf eingesetzt werden in
Anwendungen mit
• Not-Halt-Tastern
• Schutztüren

Authorised Applications

The safety relay provides a safety-related
interruption of a safety circuit.
The safety relay meets the requirements of
EN 60947-5-1, EN 60204-1 and VDE 0113-
1 and may be used in applications with
• E-STOP pushbuttons
• Safety gates

Gerätebeschreibung

Das Sicherheitsschaltgerät ist in einem
P-97-Gehäuse untergebracht. Es stehen
verschiedene Gerätevarianten für den
Betrieb mit Wechselspannungen zur
Verfügung. Jede Gerätevariante kann auch
mit 24 V Gleichspannung betrieben werden.
Standardausführung: 240 V AC/24 V DC
Merkmale:
• Relaisausgänge: 3 Sicherheitskontakte

(Schließer) und ein Hilfskontakt (Öffner),
zwangsgeführt

• Anschlussmöglichkeit für Not-Halt-

Taster, Schutztürgrenztaster und
Starttaster

• Statusanzeige
• Überwachung externer Schütze möglich
• Halbleiterausgang meldet Betriebsbereit-

schaft

Das Schaltgerät erfüllt folgende Sicherheitsan-
forderungen:
• Schaltung ist redundant mit Selbstüberwa-

chung aufgebaut.

• Sicherheitseinrichtung bleibt auch bei

Ausfall eines Bauteils wirksam.

Description

The safety relay is enclosed in a 45 mm
P-97 housing. There are different variations
for AC voltages. Every unit can also be
operated with 24 V DC.
Standard Version: 240 V AC/24 V DC
Features:
• Relay outputs: 3 safety contacts (N/O)

and one auxiliary contact (N/C), positive-
guided.

• Connections for Emergency Stop Button,

Safety Gate Limit Switch and Reset
button.

• Status Indicators
• Monitoring of external contactors/relays

possible

• Semi-conductor outputs show ready for

operation

The relay complies with the following safety
requirements:
• The circuit is redundant with built-in self-

monitoring.

• The safety function remains effective in

the case of a component failure.

Domaines d’utilisation

Le bloc logique de sécurité sert à
interrompre en toute sécurité un circuit de
sécurité.
Le bloc logique de sécurité satisfait aux
exigences des normes EN 60947-5-1,
EN 60204-1 et VDE 0113-1 et peut être
utilisé dans des applications avec des
• poussoirs d’arrêt d’urgence
• protecteurs mobiles

4

D

Betriebsanleitung

4

GB Operating instructions

4

F

Manuel d'utilisation

4

E

Instrucciones de uso

4

I

Istruzioni per l`uso

4

NL Gebruiksaanwijzing

20133-6NL-03

PNOZ X3.1

Description de l’appareil

Inséré dans un boîtier P-97, le bloc logique
de sécurité est disponible en versions
différentes pour les tensions alternatives.
Chaque relais peut également être alimenté
en 24 V DC.
Version standard: 240 V AC/24 V DC
Particularités :
• Sorties disponibles : 3 contacts à

fermeture de sécurité et un contact à
ouverture pour signalisation

• Bornes de raccordement pour poussoirs

AU, détecteurs de position et poussoir de
validation

• LEDs de visualisation
• Auto-contrôle possible des contacteurs

externes

• Sorties statique d'information (relais en

position travail)

Le relais PNOZ X3.1 répond aux exigences
suivantes :
• conception redondante avec auto-

surveillance

• sécurité garantie même en cas de

défaillance d’un composant
