Directions for use Chapter 6 Reference 61
Eight-bay battery charger specifications
Characteristic Specification
Reorder Number
Universal Battery Charger
Active C 008-0651-XX
Functional Specifications
Capacity
Eight charging bays; able to charge four (Lithium Ion) batteries
simultaneously.
Protection Classifications
a
a. Per EN 60601-1 unless otherwise stated.
Duty Cycle Continuous
Type of Protection Against Electric
Shock Class I, (Protectively Earthed) with Double Insulation
Degree of Protection Against Harmful
Ingress of Water For ordinary, indoor locations only.
Method of Disinfection Not suitable for autoclaving. (See cleaning instructions on “Inspect the
monitor, batteries, battery charger, and accessories” on page 45.)
Flammable Anesthetics Not suitable for use with flammable anesthetics.
Environmental Specifications
Operating Temperature
0° to 40° C
Shipping and Storage Temperature -20° to 60° C
Operating Altitude -2,000 to 15,000 feet (-610 to 4,572 m)
Shipping and Storage Altitude -2,000 to 40,000 feet (-610 to 12,192 m)
Operating Relative Humidity 15% to 95%, noncondensing
Shipping, Storage Relative Humidity 15% to 95%, noncondensing
Shock 30 g
Vibration 0.01g
2
/Hz from 5 to 500 Hz, 30 minutes per axis
Electromagnetic Compatibility (EMC) EN60601-1-2: 2001
Physical Specifications
Length
15.0 in (38.1 cm)
Width 9.0 in (22.9 cm)
Height 3.6 in (9.1 cm) including feet
Weight 3.5 lb (1.6 kg)
Electrical Specifications
Rated Input
100 V-240 V AC 600 mA, 50/60 ± 3 Hz, Electrical Class I
Rated Fuses T1.25 A/250V, Time-Delay 5x20mm
Rated Output per charging bay
(Continuous) 8.4 V ± 100 mV dc @1 A max.
Charge Time 4 hours typical for fully discharged battery. Automatic charge termination
when charge is completed, or fault detected.
Output Over-Current Electronic overload protection
Additional Features Detachable power cord
LED Indicators
LED OFF
No battery detected.
Flashing GREEN LED
1 sec ON, 3 sec OFF
1 sec ON, 1 sec OFF Battery detected, waiting to be charged
Battery is charged
Continuously ON GREEN LED Battery is charged.
Continuously ON YELLOW LED Battery or charging bay fault.
