16 Chapter 1 General information Welch Allyn Micropaq Monitor
Messages from Acuity
The monitor displays messages sent from Acuity as needed, including patient alarms and
equipment alerts. When Acuity messages are displayed, they temporarily override
information displayed on the lower half of the monitor screen.
Accessories
Operating settings
The following monitor operating settings can be set at the monitor or at the Acuity Central
Station:
• Patient alarm limit settings (ECG and SpO
2
).
• ECG lead and scale selection
• ECG display format
Many other monitor operating settings (such as patient mode and alarms volume) can
only be set at the Acuity Central Station. See
”Operating settings” on page 51 for a list of
all settings and where they are set.
Default settings
When the monitor connects to Acuity for a new patient, the Acuity Central Station
downloads the appropriate default settings stored at Acuity. While the monitor is
connected to Acuity, settings can be changed either at the monitor or at the Acuity Central
Station.
If the monitor is temporarily disconnected from Acuity and the operator changes settings
at the monitor, those settings are transmitted to and stored at Acuity when the monitor
reconnects.
Battery charger (8-battery) Micropaq Directions For use
Battery ECG electrodes
3-lead ECG cable (optional) 5-lead ECG cable
ECG extension cable (optional) Carrying pouch
SpO
2
sensors (Masimo or Nellcor) SpO
2
cable (Masimo or Nellcor)
WARNING Use only accessories supplied by Welch Allyn or recommended in
the Welch Allyn Products and Accessories booklet (810-0409-XX). The monitor
will only meet the listed specifications when using accessories listed by Welch
Allyn. Use accessories according to your facility’s standards and the
manufacturer’s recommendations. Always refer to the manufacturer’s Directions
for Use.
