Directions for use

Chapter 1 General information

9

Monitor features

Controls and connectors

SpO

2

Connector

ECG Connector

Visual Alarm Indicator

Liquid Crystal Display

Snapshot key

Scroll Up Key and Reset Patient Alarm Tone Key

Scroll Down Key and Main Menu Key

Select Key and
Silence Patient Alarm/
Equipment Alert Key

Back

Battery pack latch

Battery

SpO

2

connector clip

(model 408) or

cover (model

406)
