8.0 Appendix
8.1 Touchscreen Interface
The ScCMP is designed for use with touchscreen computers. Typical application layout is designed for use in a
desktop installation with a keyboard and mouse input devices. When it is required to enter information from a
keyboard, a button is provided that will bring up a dialog for entering either alphanumeric string data, or numeric
data. The button to access the touchscreen input dialogs will have the following hand icon.
When a button is pressed with this icon, one of the following touchscreen dialogs will appear prompting for the
required information.
8.1.1 Alphanumeric Dialog
Following is the ScCMP dialog for entering alphanumeric information from a touchscreen computer.
Figure 8-1. Alphanumeric Touchscreen Dialog
8.1.2 Numeric Dialog
Following is the ScCMP dialog for entering numeric information from a touchscreen computer.
Figure 8-2. Numeric Touchscreen Dialog
