KTD-S0001-C Page 5 Specifications
JRexplus LX User's Guide
Super-I/O (LPC): Winbond W83627EHG
❐
Two serial ports (RS-232 compatible)
❐
Second serial port optionally as RS-422 or RS-485
❐
One parallel port configurable as enhanced parallel port (EPP) and extended capabilities
port (ECP) with bidirectional capability
❐
One legacy floppy interface
❐
PS/2 keyboard and mouse controller
❐
Watchdog timer
Gigabit LAN (PCI): Realtek RTL8110SC
❐
Full duplex operation at 10/100/1000 Mbps
❐
Fully compliant with IEEE 802.3, IEEE 802.3u and IEEE 802.3ab
Serial-ATA (PCI): VIA VT6421L
❐
The controller supports RAID mode for up to two devices
❐
Complies with Serial-ATA specification rev. 1.0 (150 MB/s)
Digital I/O (SMBus TM ): Winbond 83601G
❐
Four inputs and four outputs, +5V signal level
External PCI bus
❐
One PCI-104 bus connector, only 3.3V PCI cards supported
BIOS: AWARD, 512 kb Flash BIOS
Real-Time Clock (RTC) with CMOS RAM and battery
