KTD-S0001-C Page 15 Graphics Interface
JRexplus LX User's Guide
7.2.3 18 Bit Digital Jumper Settings
Three jumper JP3 - JP5 allows a special configuration for pin 30 to 32 of the 18 bit digital connector.
1
The following table shows the assignment
Jumper Digital Connector
JP3 Pin 30
JP4 Pin 32 (reserved)
JP5 Pin 31
7.3 Connecting a Flat Panel
To determine whether your flat panel is supported check the Display Cable Guide on the KONTRON web site.
If you use one of those adapters supplied by KONTRON configuration is easy:
❶ Check whether you have the correct adapter and cable for the panel you plan to use. Inspect
the cable for damages. Disconnect the power from your system.
❷ Check jumper JP6 for correct panel voltage ( Pos. 1-2 = +3.3V 2-3 = +5V ).
❸ Check jumper JP2 for correct backlight voltage ( Pos. 1-2 = +12V 2-3 = +5V ).
❹ Check jumper JP1 for correct backlight on/off polarity ( Pos. 1-2 = High 2-3 = Low ).
❺ Connect the cable to the flat panel connector X17 or X18 on the JRexplus LX and connect the
other end to your display.
❻ Connect the backlight converter.
❼ Supply power to your system.
❽ If no image appears on your display connect a CRT monitor to the CRT connector.
❾ If you still do not see improvement consider contacting the dealer for technical support.
Pins Signal
1 - 2 VCC
2 - 3 GND
