KTD-S0001-C Page 54 Appendix B: Connector Layout
JRexplus LX User's Guide
Pin
PS/2 KB+MS
X8
COM A
X9
COM B
RS-232
X10
COM B
RS-422/485
X10
USB A
X12
USB B
X13
1 KBDAT /DCD /DCD TX- / (RX-) VCC5 2) VCC5 2)
2 MSDAT RXD /DSR N.C. USB0- VCC5 2)
3 GND TXD RXD RX+ USB0+ USB2-
4 VCC5 2) /DTR /RTS N.C. GND USB3-
5 KBCLK GND TXD TX+ / (RX+) VCC5 2) USB2+
6 MSCLK /DSR /CTS N.C. USB1- USB3+
7 /RTS /DTR RX- USB1+ GND
8 /CTS /RI N.C. GND GND
9 /RI GND GND KEY (N.C.)
10 VCC5 2) VCC5 2) GND
Pin
Backlight
X19
S-ATA
X4 / X5
LAN
X11
Audio
X14
Digital I/O
X15
1 N.C. GND TXD+ / BI_D1+ LINE_OUT_R OUT1
2 BKLTADJ TX+ TXD- / BI_D1- GND IN1
3 GND TX- RXD+ / BI_D2+ LINE_OUT_L OUT2
4 VCC5/VCC12 2) GND BI_D3+ LINE_IN_R IN2
5 VCC5/VCC12 2) RX- BI_D3- MIC_IN OUT3
6 GND RX+ RXD- / BI_D2- LINE_IN_L IN3
7 BKLTON GND BI_D4+ OUT4
8 BI_D4- IN4
9 VCC5 2)
10 GND
Pin
Common Front
Panel FP1
Power Front
Panel FP2
Main Power
X22
Power Supplem.
X23
1 RST_BTN+ PWR_LED+ VDD 2) /PS_ON
2 SPKR+ PWR_BTN+ GND 5VSB 2)
3 RST_BTN- N.C. GND
4 N.C. PWR_BTN- VCC 2)
5 HDD_LED+ PWR_BTN-
6 N.C. N.C.
7 HDD_LED- RSVD
8 SPKR- RSVD
9 GND
10 RSVD
Note: 1) Not supported on the JRexplus LX board.
2) To protect the external power lines of peripheral devices make sure that
- the wires have the right diameter to withstand the maximum available current.
- to enclosure of the peripheral device fulfills the fire-protecting conditions of IEC/EN 60950.
