Setup Guide
JRexplus LX User's Guide
22.8 Power Management Setup
Feature
Option
Description
Power Management
Disabled
ACPI
Enables or disables the ACPI power management
ACPI Suspend Type
S1 (POS)
Selects >Power On Standby< (S1)
22.9 PC Health Status
Feature
Option
Description
Shutdown Temperature
Disabled
60
0
C / 140
0
F
65
0
C / 149
0
F
70
0
C / 158
0
F
Defines the shutdown temperature
System Temperature
N/A
Local temperature
CPU Temperature
N/A
Temperature of CPU
Board Voltage +Vcore
N/A
+Vcore voltage (generated onboard)
Board Voltage +2.6V
N/A
+2.5V voltage (generated onboard)
Board Voltage +3.3V
N/A
+3.3V voltage (generated onboard)
Board Voltage +5Vsb
N/A
+5V standby voltage (external or onboard)
System Voltage +5V
N/A
+5V voltage (external power supply)
System Voltage +12V
N/A
+12V voltage (external power supply)
22.10 Board Information
Feature
Option
Description
BIOS Version
N/A
Shows the actual BIOS version
BIOS Date
N/A
Shows the BIOS production date
LX800 Chip Rev.
N/A
Shows the Northbridge (LX800) chip revision
CS5536 Chip Rev.
N/A
Shows the Southbridge (CS5536) chip revision
Board Class
N/A
Shows the KONTRON specific board class
Board Name
N/A
Shows the KONTRON specific board name
Hardware Version
N/A
Shows the KONTRON specific hardware version
Manufacturing Date
N/A
Shows the KONTRON specific manufacturing date
Serial Number
N/A
Shows the KONTRON specific serial number
Boot Counter
N/A
Shows the actual boot counter
