Appendix B: Connector Layout

JRexplus LX User's Guide

B.3 Mating

Connectors

The table notes mating connectors.

Identifier

Mating Connector

Comment

X10

1.25 mm 10 pin

(MOLEX 50058-8000 or comp.)

for standard DSUB9 adaptation

X14

2.50 mm 6 pin

(JST SXH-002T-P0.6 or comp.)

for audio support (Line In, Line Out
and Microphone)

X19

1.25 mm 7 pin

(MOLEX 51021-0700 or comp.)

for backlight cables
