KTD-S0001-C Page 46 Appendix A: System Resources
JRexplus LX User's Guide
A.4 I/O Address Map
The I/O-port addresses of the JRexplus LX are functionally identical to a standard PC/AT. All addresses not
mentioned in this table should be available. We recommend that you do not use I/O addresses below 0100h
with additional hardware for compatibility reasons even though they are available.
I/O Address Used for Available Comment
01F0h - 01F7h AMD PCI P-ATA Controller No Note (1)
0278h - 027Fh Yes Possible address of LPT2
0290h - 0297h Hardware Monitor No
02E8h - 02EFh Yes Possible address of COM4
02F8h - 02FFh Serial Port 2 No Note (1)
0378h - 037Fh Parallel Port 1 No Note (1)
03BCh - 03C4h Yes Possible address of LPT3
03B0h - 03DFh Graphic Controller No
03E8h - 03EFh Yes Possible address of COM3
03F0h - 03F7h Floppy Controller No Note (1)
03F8h - 03FFh Serial Port 1 No Note (1)
0480h - 048Fh DMA Extension No Chipset
04D0h - 04D8h PIC Extension No Chipset
0CF8h - 0CFFh PCI Configuration No Chipset
6000h - 63FFh AMD PCI ISA-Bridge No Chipset
9C00h - 9FFFh AMD PCI ISA-Bridge No Chipset
AC1Ch - AC1Fh AMD PCI Host Bridge No Chipset
F400h - F4FFh VIA PCI S-ATA Controller No Onboard PCI device
F600h - F6FFh Realtek PCI LAN Controller No Onboard PCI device Note (1)
F900h - F91Fh VIA PCI S-ATA Controller No Onboard PCI device
FA00h - FDFFh VIA PCI S-ATA Controller No Onboard PCI device
FE00h - FE7Fh AMD PCI Audio Controller No Chipset Note (1)
FF00h - FF0Fh AMD PCI P-ATA Controller No Chipset Note (1)
Note: 1) If the Used for device is disabled in the BIOS Setup the corresponding address is free.
