Kontron JRexplus-LX - Manual (Page 43)

KTD-S0001-C Page 39 Setup Guide
JRexplus LX User's Guide
22.3.1 IDE Master or Slave Submenu
Feature Option Description
HDD Auto-Detection Press Enter Executes HDD auto-detection
Master/Slave Drive None
Auto
Manual
None = disable drive
Auto = auto-detection: the drive itself suppli-
es the information
Manual = end user supplies the HDD informati-
on
Access Mode CHS
LBA
Large
Auto
CHS = physically 28bit addressing mode
LBA = adressing mode with logical block num-
bers
Large = for drives that do not support LBA and
have more than 1024 cylinders
Auto = auto-detection: the drive itself suppli-
es the information
Capacity N/A Displays the calculated size of the drive
Cylinder N/A Number of cylinders
Head N/A Number of read/write heads
Precomp N/A Write precompensation cylinder number
Landing Zone N/A Defines the head park position
Sector N/A Number of sectors per track
22.4 Advanced BIOS Features
Feature Option Description
8Hard Disk Boot Priority Press Enter Selects hard disk boot device order
Virus Warning Enabled
Disabled
Enables or disables the virus warning for P-ATA
harddisk boot sector
First Boot Device
Second Boot Device
Third Boot Device
Floppy
Hard Disk (Third)
CDROM (Second)
USB FDD (First)
USB-CDROM
LAN
Disabled
Standard legacy diskette drive
Primary hard drive
Standard CDROM or DVD drive
USB diskette drive
USB CDROM drive
LAN controller with LAN Boot-ROM
Disables boot device
Boot Other Device Disabled
Enabled
Enables or disables other boot devices
Security Option Setup
System
Setup = password required for Setup
System = password required for system boot
JRC Extension Enabled
Disabled
Enables or disables the JRC extension (remote
control)
Darkboot / Custom Logo Disabled
Enabled
If enabled normally Darkboot will be active.
For Custom Logo contact KONTRON
