Getting Started
JRexplus LX User's Guide
4
Getting Started
Getting started with the JRexplus LX is very easy. Take the following steps:
❶
Plug a suitable DDR-SDRAM memory module into the RAM socket.
❷
Connect the CRT monitor to the CRT interface or a LCD panel to the JILI30 interface respecti-
vely the 18 bit digital interface by using the corresponding adapter cable.
❸
Plug a keyboard and/or mouse to the combined PS/2 connector by using a Y-cable.
❹
Plug a data cable to the hard disk interface. Attach the hard disk to the connector at the oppo-
site end of the cable. If necessary connect the power supply to the hard disk’s power connec-
tor.
❺
Make sure all your connections have been made correctly. Turn on the power.
❻
Enter the BIOS by pressing the Del key during boot-up. Make all changes in the BIOS Setup.
See the BIOS Setup chapter of this manual for details.
